How-to Guides

This section will going to guide you through PEAK’s fundamental ideas and functionalities. Every example given here is available in the repository.

PEAK Basic principles

You have two options to run PEAK agents. You can run the same way as in SPADE by using a python script or using PEAK’s command line interface (CLI).

Note: After installing peak you can use the command -h to show you the commands available to you. e.g.

$ peak -h
usage: peak [-h] [-version] [-v] {df,run,start} ...

positional arguments:
 {df,run,start}
   df            Execute Directory Facilitator agent.
   run           Execute PEAK agents.
   start         Executes multiple agents using a YAML configuration
                 file.

optional arguments:
 -h, --help      show this help message and exit
 --version        show programs version number and exit

How to create and Agent (Example 1)

Let’s run a simple agent.

# agent.py
from peak import Agent, OneShotBehaviour

class agent(Agent):
    class HelloWorld(OneShotBehaviour):
        async def run(self) -> None:
            print("Hello World")
            await self.agent.stop()

    async def setup(self) -> None:
        self.add_behaviour(self.HelloWorld())

Consider the agent above. Create a file called agent.py and copy the code. This is a simple agent that will print “Hello World” in the terminal.

To execute the agent you only need to open the directory where the file agent.py is in the CLI and then use the following command.

$ peak run agent.py -j dummy@localhost

Note: The name of the file must be the same as the name of the class. That is the only way for PEAK to know which objects to run when executing an agent.

In this command we are telling PEAK to run the agent that is in the file agent.py with the JID dummy@localhost.

The JID is the ID used in the XMPP protocol and is divided by three parts: the localpart, the domain and the resource (localpart@domain/resource). The localpart is required and is the username of the agent. The domain is also required and is the domain of the server you want the agent to log in. The resource is optional and is used to differentiate sessions of the the same user. The resource, when empty, is created randomly.

After you run the agent you will see a new folder appear in the same directory of the agent.py. That folder is the logs folder and will contain the log files created for each agent you run. You can change the logging level for each agent using the command line argument -l. This files come in handy when running complex systems with lots of behaviors. You can track everything the agent does and when it does with the logging functionality.

Communication between Agents (Example 2)

To run multiple agents at the same time you can use a configuration file in YAML format.

# sender.py
from peak import Agent, OneShotBehaviour, Message

class sender(Agent):
    class SendHelloWorld(OneShotBehaviour):
        async def run(self):
            msg = Message(to="harry@localhost")
            msg.body = "Hello World"
            await self.send(msg)
            await self.agent.stop()

    async def setup(self):
        self.add_behaviour(self.SendHelloWorld())

# receiver.py
from peak import Agent, OneShotBehaviour

class receiver(Agent):
    class ReceiveHelloWorld(OneShotBehaviour):
        async def run(self):
            while msg := await self.receive(10):
                print(f"{msg.sender} sent me a message: '{msg.body}'")
            await self.agent.stop()

    async def setup(self):
        self.add_behaviour(self.ReceiveHelloWorld())

# mas.yaml
defaults:
    domain: localhost
agents:
    john:
        file: sender.py
    harry:
        file: receiver.py

Let’s create two agents one that sends the a message, the sender.py, and one that receives the message, the receiver.py. In the same directory create the YAML file above with the name mas.yaml. After that, run the following command:

$ peak start mas.yaml

So, what happened? Two agents were created. One called john@localhost and the other called harry@localhost. john sent a Hello World to harry and harry printed it out.

The way it works is simple. You can only define two root variables, the defaults and the agents. The defaults is used to define parameters to be applied to all agents. The agents variable defines the list of agents to be executed and their individual parameters. Type peak start -h on the terminal to see the list of available parameters.

In this case we are defining, in the defaults, the default domain as localhost for all agents. In agents variable, we are defining two different types of agents, the john and the harry. In both agents we are defining their source file. The agents parameters will override the defaults parameters if they are the same.

There is the list of options that you can define in the configuration file, inside each agent and in the defaults variable:

file - source file of the agent
domain - domain of the server to be used for the agent’s connection
resource - resource to be used in the JID
log_level - logging level of the log file
clones - number of clones to be executed
verify_security - if present verifies the SSL certificates

Thread vs. Process

In development This section will talk about how to run agents as different threads of the same process or as multiple processes and the benefits and use cases for each approach.

PEAK Communities

In PEAK, communities can be seen as groups of agents that share similar goals. Communities are a very useful and efficient way to make communication between three or more agents. What makes this usefull is that for each message sent to the community every member will receive the message.

For this examples you will need to execute a pre-defined PEAK agent called Directory Facilitator, for short DF. He is responsable to maintain the PEAK communities structures. More details about the DF here.

Creating a community (Example 3)

To create a community is very simple. There is a pre defined behavior that enables the agent join communities. For only this functionality you don’t need DF, but it is recommended.

#agent.py
from asyncio import sleep

from peak import Agent, JoinCommunity, LeaveCommunity, Message, OneShotBehaviour


class agent(Agent):
    class HelloWorld(OneShotBehaviour):
        async def on_start(self):
            await self.wait_for(JoinCommunity("group1", f"conference.{self.agent.jid.domain}"))

        async def run(self):
            msg = Message(to=f"group1@conference.{self.agent.jid.domain}")
            msg.body = "Hello World"
            await self.send_to_community(msg)
            await sleep(5)
            msg.body = "Goodbye World"
            await self.send_to_community(msg)
            self.kill()

        async def on_end(self):
            await self.wait_for(LeaveCommunity("group1", f"conference.{self.agent.jid.domain}"))
            await self.agent.stop()

    async def setup(self):
        self.add_behaviour(self.HelloWorld())

Then run the following command:

$ peak run agent.py -j dummy@localhost

As you can see in the example above, the agent has a behavior HelloWorld. This behavior will first use the JoinCommunity behavior to join a community called group1@conference.localhost. If the community does not exists it will create it automatically. It waits until the agent joins the community. After that it will send a Hello World message to the community, waits for 5 seconds and then sends a Goodbye World and leaves the community with the LeaveCommunity behaviour.

Note: For the this functionality to work the server must have Multi-User Chat functionality activated. You need to create a component in the server and give it a prefix, in this case is ‘conference’. See this server configuration file example.

Tip: You can see the messages being sent if you use the XMPP client and enter in the same room as the agent. Is a good way to debug the multi-agent.

Chalenge 1: Try to implement the Communication between agents example using communities. (Solution)

Community tagging (Example 4)

Community tagging, as the name suggests, is for tagging communities. This allows the agents to identify the communities and then search for them using the tags to filter them. Let’s see.

#agent.py
from peak import Agent, JoinCommunity, LeaveCommunity, OneShotBehaviour, SearchCommunity


class agent(Agent):
    class TagCommunities(OneShotBehaviour):
        async def run(self) -> None:
            self.agent.add_behaviour(
                JoinCommunity(
                    "group1",
                    f"conference.{self.agent.jid.domain}",
                    ["test", "awesome"],
                )
            )
            self.agent.add_behaviour(
                JoinCommunity(
                    "group2", f"conference.{self.agent.jid.domain}", ["test"]
                )
            )
            def print_communities(tags, communities):
                print(f"Communities ({tags}): {communities}")

            await self.wait_for(SearchCommunity(["awesome"], print_communities))
            await self.wait_for(SearchCommunity(["test"], print_communities))

            await self.wait_for(
                LeaveCommunity("group1", f"conference.{self.agent.jid.domain}")
            )
            await self.wait_for(
                LeaveCommunity("group2", f"conference.{self.agent.jid.domain}")
            )
            await self.agent.stop()

    async def setup(self) -> None:
        self.add_behaviour(self.TagCommunities())

For this to work you need to execute the DF agent (more details here). In the example above we create an agent that will create and tag two communities: group1@conference.localhost with tags test and awesome, and group2@conference.localhost with tag test. After that will search for communities using the SearchCommunity behavior. Note that for the SearchCommunity and for LeaveCommunity behaviours we do not add the behaviour directly to the agent, because the agent would stop before the behaviours would be accomplished. We use wait_for method, available in every behaviour, to wait for the completeness of the behaviour before continuing, making the behaviour synchrounous.

In simple words the tagging system will search for the communities that have the tags that you want. For instance, if you search for three tags it will give you every community that have all those three tags.

Chalenge 2: Try to implement this example with two agents: one that creates and tags the communities and other that searches for them. (Solution)

Community hierarchy (Example 5)

The community hierarchy allows the user to create different levels of communities associated with one another. This does not only allow your agents to organize themselves but also to communicate more efficiently through the hierarchical branches. For instance, consider the hirarchy bellow.


For every community of the hierarchy two nodes are created: the actual node of the community, which only the members can interact, and a node which has all the members of that community all the way down to the roots. This special node that we call the echo node will work has an echoer for the whole branch beneaf. In other words, if you want to send a message from X to Y you just need to send a message to the X_down node.

Let’s see an example of the community hierarchy.

#agent.py
# Standard library imports
from asyncio import sleep

# Reader imports
from peak import Agent, JoinCommunity, LeaveCommunity, Message, OneShotBehaviour


class agent(Agent):
    class HelloWorld(OneShotBehaviour):
        async def run(self):
            groups_tree = [
                "peak/A0/B0",
                "peak/A0",
                "peak/A1",
                "peak/A2/B2/C0",
                "peak/A1/B3/C1",
            ]
            for groups_branch in groups_tree:
                await self.wait_for(
                    JoinCommunity(groups_branch, "conference." + self.agent.jid.domain)
                )
                await sleep(1)
            for groups_branch in groups_tree:
                await self.wait_for(
                    LeaveCommunity(groups_branch, "conference." + self.agent.jid.domain)
                )
                await sleep(1)
            await self.agent.stop()

    async def setup(self):
        self.add_behaviour(self.HelloWorld())

For this to work you need to execute the DF agent (more details here). In the JoinCommunity behavior you can specify a path representing the hierarchy of the communities. For instance in path peak/A0/B0, peak is the root community, beneath is community A0, at level 1, and B0 at level 2. The last node of the path does not need necessarilly to be a leaf. We call the last node the target onde, because you only enter in that community specifically.

Note: In the Dashboard, the groups that end in _down do not appear in the node graph.

Simulation Environment

Clock

Dynamic clock

In development

PEAK Dashboard

The PEAK Dashboard is a separate project from PEAK. The Dashboard allows you to see in an interactive way the PEAK ecosystem using a web app. The Dashboard needs a Directory Facilitator (DF) agent in the XMPP server so it can monitor the system. The Dashboard communicates with the DF through its REST API. To know how to activate the DF run the following command:

$ peak df -h
